FTDX 1200 HF/50MHz Transceiver

Continuing the Yaesu “FT DX” Legacy of Excellence established decades ago, the FT DX 1200 is designed for the casual operator as well competitive operating situations, whether you primarily operate in Contests, chase DX or enjoy Field operating. The High Frequency Design Technology it has inherited ensures “Best in Class Performance”.
The FT DX 1200 provides up to 100 Watts on SSB, CW, FM, and AM (25 Watts carrier) and a rugged state of the art highly balanced receiver circuit configuration for top performance on today’s crowded bands. Similar to the high-end “YAESU FT DX” series, it uses 32-bit high speed floating point DSP for renowned proven performance.
A built-in 4.3-in TFT wide full color High Resolution Display with loads of information provides superior operability and visibility for the FT DX 1200 user. A Spectrum Scope located just below the LCD display gives the operator all the information needed to place them at the right place on the band with the right receiver set-up to have a satisfying experience with a casual QSO chat or while digging out a rare desired weak signal contact.
Optional Accessories are offered to provide very desirable additional features that make the FT DX 1200 a flexible true high performance platform for all hams – no matter what mode they chose to operate.

160 through 6 Meters – SSB/CW/FM/AM/Digital

With efficient dimensions of 14.4″ x 4.5″ x 12.3″ (W x H x D) and weighing in at only 20.9 pounds, the FT DX 1200 is a solidly packed transceiver ready to give very high performance on all Amateur Radio bands from 160 to 6 meters.

• General Coverage Reception from 30 kHz to 56 MHz

• FM & AM – Wide and Narrow modes included

100 Watts of Solid Performance

The RF Final Amplifier produces a clean 100 watt (some modes less) transmit signal. A large heat sink is combined with the die cast aluminum chassis for efficient heat dissipation. A cooling fan located beside the final amplifier and the TX Low Pass Filter ventilates the heat away from inside of the transceiver cabinet. This large axial flow fan is mechanically isolated from the chassis to reduce vibration and noise. The speed of the fan is continuously controlled by the temperature of the PA amplifier; starting at 40 degree C.

Antenna Tuner Included

High Speed Automatic Antenna Tuner included. The antenna tuner uses LC switching. It has a large capacity 100 channel memory; the tuning data is automatically memorized to reduce tuning time when changing frequency.

Smooth Main Tuning Knob Feel

The Main Tuning Knob, made from marchined aluminum parts, has the solid feeling of a largre flyweheel, while being nimble and smooth in operation. Each user may set his/her favorite torque feeling of the Main Dial rotation.

USB Capable

The FT DX 1200 can be connected to a PC with a USB cable through the use of an optional SCU-17 Interfeace Unit. This unit will support CAT, USB Audio In/Out, TX control (PTT, Key, Shift), and firmware updates.

Remote Control From A Distant Location

External control (CAT) is possible using Serial Port or the optional SCU-17 USB Interface Unit. This feature means the FT DX 1200 can be remotely controlled from a distant location!

Big TFT Full-Color Display For Superior Operability and Visibility

The FT DX 1200 presents a wide view angle, high contrast LCD 4.3 inch TFT impressive full color display that provides a convenient view of the radio’s working functions. Superior operability is realized with this convenient display. It permits excellent visibility from different viewpoints. Even with the many FT DX 1200 features and functions, the TFT display makes operation of the radio easy and comfortable.

• A Block Diagram Displays RX Signal Path
• Choose Analog Type or Bar Graph Meter
• Separate VFO-A, VFO-B Transmit and Receive Frequency Display
• Bandwidth of the spectrum scope: 20kHz, 50kHz, 100kHz, 200kHz, 500kHz, or 1MHz
• TX and RX markers appear during “spit” operation
• Level Indicator
The function names and the setting levels of the following functions are shown in the TFT main display when a function knob is rotated: Clarifier, Microphone Gain, Speech Processor, SHIFT, WIDTH, KEYER SPEED and CONTOUR
• Cursor Keys
Six keys that are used frequently in normal operation are located at the left side of the TFT display. Other functions can be operated by pressing the “SCOPE” key which changes the “Spectrum Scope screen” to “Function Key Display screen”. Even if the radio is turned off, the last operated Key Function is memorized and highlighted.
• Spectrum Scope
The FT DX 1200 has a standard automatic sweeping high speed spectrum scope in line with dial operations. The spectrum scope function that allows for an instant view of the signals, their strengths and distribution within a band is supplied as standard. The spectrum scope sweep function has two modes available: the normal mode, where the band is swept once when the SELECT button is pressed, and the AUTO mode where the band is automatically swept at preset intervals. No receive audio is generated during sweeping, but as sweeping is done at an extremely high speed this is a brief instant of approximately 300 msec. If the operator quickly operates the main dial to make a big frequency change in AUTO mode, an automatic sweep is performed and the display is refreshed. This enables frequency tuning while checking the spectrum in real time. The moment tuning is halted the receive frequency audio is resumed; as no sweeping is performed during slow frequency changes to tune in to another station, there is no interruption to the receive audio. Operation therefore feels natural and is without stress. Additonal scope features include:
1. Six different options: 20 kHz, 50 kHz, 100 kHz, 200 kHz, 500 kHz and 1 MHz.
2. TX and RX markers are displayed in the spectrum scope, enabling the user to confirm the relationship between the receive and transmit frequencies at a glance. This is particularly useful in the case of split operation.
3. Full TFT screen signal spectrum can be viewed in detail by simply pressing the SCOPE key.
• Optional FFT-1 Unit provides the following additional features:
1. AF-FFT (Audio Frequency Fast Fourier Transform) scope.
This AF-FFT function was first demonstrated in the FT DX 9000 series. With this Scope, the audio characteristics of the received signals; the effect of adjusting the RX IF filter performance; and utilizing the QRM rejection features, may be visually observed. It is also possible to observe the TX audio characteristics of your own signal while using the Monitor function. This is very effective for tuning the parametric equalizer for voice characteristics and the microphone audio.
2. RTTY/PSK31 Encode Decode
3. CW Decode
4. CW Auto Zero-in

Superior Triple Conversion Receiver

The FT DX 1200 high performance triple conversion receiver circuit structure enables elimination of unwanted signals through filters at each stage as well as optimized gain distribution.

Top Performing Receiver RF Front End

The receiver front end is exposed to strong signals directly from the antenna. Yaesu engineers carefully selected and tested active elements like the RF amplifier, but also passive circuit components and coils, so that no spurious or unwanted signals are created. By pressing the ATT key on the front panel, the operator picks from four selectable stages of attenuation to attenuate interfering strong signals. The effect of strong out of band interfering signals on the RF amplifier is further reduced by significant attenuation through 8 band pass filters in the FT DX 1200.

Effective QRM and QRN Rejection

Effective QRM rejection is achieved from the FT DX 1200 IF DSP. The 32-bit high speed floating decimal point DSP, TMS320C6727B (maximum 2800 MIPS/ 2100 MFLOPS) made by Texas Instruments, is used for the IF section of the FT DX 3000. The signal is processed with the high speed 300 MHz clock frequency.
• Proven IF WIDTH and IF SHIFT functions provide great QRM rejection performance
With the normal bandwidth, the pass band area can be moved relatively, so that harmful signals are rejected from the pass band
By adjusting the band width, Interfering signals can be removed from both sides of the pass band, without changing the pass band position. The IF width function can make the pass band narrower with one-touch. This function is effective in a pile-up or contest, when the undesired signals are located just above and below the target signal.
The CONTOUR function ideally tailors the received audio signal without changing the bandwidth. The CONTOUR function varies the outline of the IF DSP filter pass band characteristics, and the in-band signal construction can be partially altered. Different from the IF SHIFT or IF WIDTH, the special CONTOUR pass band, can reduce or peak the desired signal, partially and continuously across the pass band. This feature is effective especially when the undesired signal is close to the center frequency.
• Digital Noise Reduction (DNR) by DSP
The installed digital noise reduction circuit provides 15 separate parameters. The noise reduction constants may be set to the optimal working point by varying the 15 step parameters according to the actual noise within the HF band. The desired signal components are peaked and the random noise components are effectively cancelled.
This high Q circuit has steep attenuation characteristics of 70dB or more. Effective removal of a strong beat signal is obtained. The damping characteristics can be switched to wide or narrow band width, and the attenuation level may be adjusted in the Setting Mode Menu. Interfering signals may be attenuated, while minimizing the impact on the received signal.
• CW APF (Audio Peak Filter)
In the CW mode, the APF (Audio Peak Filter) function has an audio peak at the signal frequency; this improves the S/N and increases the readability of the CW signal. The APF peak frequency can be finely aligned.

Selectable Roofing Filers

Roofing filters of 3 kHz, 6 kHz and 15 kHz filters are fitted before the 40.455 MHz 1st IF. These filters reduce the later burden on the receiver mixer and improves the adjacent multi signal characteristics.

Very Low Noise Floor – Terrific Signal to Noise Ratio

The S/N ratio (signal-to-noise ratio) of the local signal that is injected into the 1st IF mixer is one of the most important factors for improving the receiver properties in the ultra-multi-signal environment.

In the FT DX 1200, the combination of it’s high stability and high accuracy 40 MHz TCXO (± 0.5ppm, -10 °C ~ +60 °C), and it’s DDS create the fundamental frequency of this radio, and is locked to the PLL-IC and VCO directly. This circuit construction and method creates the highest quality local signal, with superior S/N performance.

Three IPO Settings – Best Signal Reception During Changing Band Conditions

3-step IPO settings permit the operator to select the most appropriate gain for best signal reception. This variety of selections provides superior receiver performance and the best possible communications with changing band conditions.

The IPO (Intercept Point Optimization) is selected by a control switch located on the front panel. The IPO selection determines the gain of the RF amplifier. The gain setting is very effective in optimizing the receiver performance, depending on the antenna and the communication propagation conditions. The IPO, the ATT and one stage of the RF amplifier are used to optimize the signal levels that are sent to the mixer.

High Quality Audio With Punch

The modulation circuit of the FT DX 1200 utilizes digital variation operational modulation, which creates ideal high quality transmission audio.
• Microphone Amplifier that includes Parametric Equalizer
The modulation circuit of the FT DX 1200 utilizes the digital variation operational modulation type, which creates ideal high quality transmission audio. This radio has a parametric equalizer that makes possible versatile adjustment of the TX audio quality by aligning the TX band audio spectrum. The parametric equalizer can alter the Low, Mid and High part of the audio separately. This three stage parametric equalizer can generate high quality TX audio sound because it can be tuned in detail…without sacrificing the audio dignity.
• IF DSP Speech Processor – DX’er and Contester Proven
The SSB Speech Processor uses IF digital signal processing to increase the intelligibility of the transmitted signal during weak signal crowded conditions. The DSP increases the average power of the important speech spectrum components and reduces the TX power of the less significant components. Adjust the compression level in the Menu Mode to adapt the transmitted SSB signal to best suite your voice characteristics, the situation, propagation conditions and pile-up demands.

Two Antenna Inputs

Two antenna connectors are available on the FT DX 1200 Rear Panel.
• Having multiple antenna selections is an especially effective feature for DX and Contest operating.
• Antenna connection selections memorized and recalled when changing bands.
• It is possible to use Ant 1 for transmit and Ant 2 for receive.

For the CW Enthusiast

CW Zero-in Display
The TX CW side tone pitch frequency can be adjusted in the MENU. The setting range is 300 Hz to 1050 Hz. This tone pitch is used as the reference in transmission. This means that the point, at which the TX pitch is equal to the RX pitch, becomes the zero-in point.

In addition, the FT DX 1200 has a CW tuning display feature. By using this function, as the pitch of the sound that is heard when receiving the CW signal becomes closer to the programmed pitch, the lighted mark moves closer to the center of the display. When the center mark light turns RED, the signal is at the zero-in point.

CW APF (Audio Peak Filter)
In the CW mode, the included APF (Audio Peak Filter) function has an audio peak at the signal frequency; this improves the S/N and increases the readability of the CW signal. The APF peak frequency can be finely aligned. APF bands can be selected from three steps according to preference, whereas peak frequencies can be fine-tuned with the APF switch located on the front panel.

Other CW Features
• Dial step setting (for the CW mode only)
• CW SPOT Feature
• CW Full Break-in
• CW “VOX” Delay is adjustable
• CW Mode reversal (USB or LSB)
• CW Keying available during SSB operation
• Separate KEY Jacks on the front and rear panels
• Electronic Keyer Included
• Four-channel Message Memory (50 characters each); five memories available with FH-2 Keypad (optional)
• Automatic “Beacon” keyer mode

Optional Fully-Automatic µ-Tuning Kit

The u-Tuning Kit that was developed for the FT DX 9000, is optionally available for use with the FT DX 1200. No other Amateur Radio transceiver manufacturer offers a comparable device that may improve your DXing performance in some challenging operating situations.

A large diameter with an adjustable ferrite magnetic material (Ni-Zn ferrite) core, is combined, with a high resolution and high torque stepping motor to automatically find the resonance point. By inserting these tuning units prior to the RF front end of the receiver, the IP3 points are improved by around 4 dB. Three individual tuning units are available covering frequencies from 1.8 MHz through 14 MHz. Many FT 950, FT 2000/D, FT DX 3000, FT DX 5000 and FT DX 9000 Yaesu customers have used them and found them especially effective for use on the Lower Bands.FTDX3000

Paul Leicester | MØFOX | Chesterfield UK | IO93HE | Yaesu FTDX1200.

Yaesu Digital FTM-100DR



Introducing the FTM-100DR VHF/UHF Dual Band Transceiver, an exciting new way to enter into Yaesu’s revolutionary world of System Fusion C4FM Digital Communications. The FTM-100DR’s single receiver design provides 50 solid Watts of RF power on both the 144 and 430 MHz amateur radio bands, while still being host to a feature packed suite of both C4FM Digital and FM Analog communications capabilities that fit every amateur radio operators needs.

Designed with simplicity and convenience in mind, the FTM-100DR’s highly visible and compact 160 x 40 pixel graphical dot-matrix display can be detached from the body of the radio and remotely mounted providing even more installation options. This vibrant white LED backlit display provides a clear and crisp view of the radios current operating status, not limited to GPS Information, SD Card status, and Operating band name/memory channel tags (Alphanumeric).

The FTM-100DR operates in three (3) Digital modes and an (1) Analog mode to suit your needs. This feature packed radio is our first Digital Mobile equipped with our new Automatic Mode Select (AMS) function that instantly detects the received signal mode. The AMS function enables stress-free operation and eliminates the need to manually switch between communication modes.

·V/D Mode (Voice/Data simultaneous communication mode)

The digital voice signal is transmitted in one half of the band width. Simultaneously the other half of the 12.5 kHz band width channel is used for error correction of the voice signal and other data. By incorporating powerful error correction technology developed for professional communication devices, effective error correction codes provide the advantage of fewer interruptions to conversations. The Clear Voice technology developed for the C4FM FDMA Digital mode provides the ideal balance of error correction and sound quality.

·Voice FR mode (Voice Full Rate Mode)

This mode uses the full 12.5 kHz bandwidth to transmit digital voice data. The increased amount of voice data permits high quality voice communication, providing superb sound quality for a “rag chew” with friends.

·Data FR mode (High Speed Data Communication Mode)

This high-speed data communication mode uses the full 12.5 kHz bandwidth for data communication. The transceiver automatically switches to Data FR mode when transmitting snapshot pictures, and can be used to transmit large quantities of data at high speed.

·Analog FM mode

Analog FM is effective when weak signal strength causes audio drop out in the digital mode, and enables communication up to the borderline of the noise level. Also the use of established Yaesu low power circuit designs provides greater efficiency than the digital modes. This is the typical FM mode used by most typical non-digital handhelds and VHF/UHF mobiles.

Digital and Analog FM Capable
There is no reason to lose communications with friends who have not yet chosen to transition to Digital. The FTM-100DR performs perfectly well using both Analog FM and C4FM Digital, and can flawlessly integrate into either operating environment.
Rugged Powerful Transmitter
Transmitter RF Power Output: 50 W / 20 W / 5 W. Modulation Type: F1D, F2D, F3E: Variable Reactance Modulation, F7W: 4FSK (C4FM)
High Audio Output Power
Loud 3 Watt Audio Outputs with the internal speaker. 8 Watt output using Optional External Speaker (MLS-200-M10)
Large BUSY/TX Indicator
Two large and vibrant multi-colored BUSY/TX LED status indicators clearly show the current operating state of the transceiver, turning Green when receiving an analog FM transmission and blue when receiving digital.
• The top half lights green when in the BUSY/RX state.
• The top half lights red during transmission.
• The bottom half lights blue while receiving or transmitting digital voice signals.
• The bottom half lights white while receiving or transmitting digital data.
• The bottom half blinks blue when receiving the signal containing a different TONE frequency or DCS code other than the one configured.
GPS Included
Built-in 66 channel GPS receiver and antenna provides location, time, direction and APRS® information. A GPS Logging Function is included.
APRS® Included
1200/9600bps APRS® (Automatic Packet Reporting System) Data communication capability included.
Hands-free Operation
Law abiding (where required) Hands-free operation is available by using the optional wireless Bluetooth® unit and headset. Optional Bluetooth® unit (BU-2) required.
Voice Guide and Recording Function
Optional Voice Guide Unit (FVS-2) announces your current operating frequency, band change and APRS® messages. You can record up to 5 minutes of received signals, or continuously record the last 30 seconds of received audio.
Digital Group Monitor (GM) Function
The digital GM function automatically checks whether members registered to a group are within the communication range, and displays information such as the distance and orientation for each call sign on the screen. This useful function not only enables you to see which friends are within communication range, it also permits you to see at a glance where all group members are located. Additionally, this function can be used to send messages and image data between group members. The Digital Group Monitor applies to direct communications between members; it is not applicable through a repeater.

This is valuable feature for public service group activites, Search & Rescue operations, and any number of other uses limited only by your imagination!
Frequency Range
108 – 137 MHz (Air Band)
137 – 174 MHz (144 MHz HAM)
174 – 400 MHz (GEN1)
400 – 480 MHz (430 MHz HAM)
480 – 999.99 MHz (GEN2) Cellular Blocked (North American model)
144 – 146 MHz or 144 – 148 MHz
430 – 440 MHz or 430 – 450 MHz
Other Useful Features
– 500 Memory Channels for each A(Main) band and B(Sub) band
– Storage of the Memory channels and personal settings on an inserted micro SD card
– By using a micro SD card, it is easy to copy and transfer the radio data to other compatible radios
– Versatile Scanning Receiver for Monitoring Enthusiasts (VFO Scan, Memory Scan, etc)
– Digital Clock
– Timer function: Event timer with Lap or count down functions
– Receives and Forwards Digital Image Data (Does not support MH85A11U Camera Microphone). Yaesu-FTM-100DR

Yaesu Digital FTM-100DR

Paul Leicester | MØFOX | Chesterfield UK | IO93HE | Yaesu FTDX1200.

LP-100A Digital Vector Wattmeter

D7K_3792_Version_2 DSCN8946c LP-100A_rear_dual-b
LP-100A Digital Vector Wattmeter
Everything you need for critical station monitoring, tuning and protection on one screen. No other meter has dual bargraphs, OR a graphic display with solid bargraphs, OR bargraph with 90 bars for fine tuning of Power and SWR, OR an SWR alarm with snooze mode, OR a “sticky” bar for graphic peak hold indication… let alone having them all on one screen! This is by far the best display for tuning a manual tuner, without having to change display mode for normal operation. It is also the only meter with 11 bands of frequency indexed NIST traceable calibration points using a built-in frequency counter.
Plus, the LP-100A has additional modes no other wattmeter has when you desire them… vector impedance, dBm/RL, calibrated field strength and compression ratio.
Dual Coupler Option Two couplers… one LP-100A… auto-sensing… perfect for SO2R. Better than “paralleled” couplers because the couplers are isolated from each other, and each has its own Calibration table.

LP-100A Features & Specs

* Dual Coupler Option. Allows one LP-100A to use two couplers, with auto-sensing and switching to the active coupler.
Great for SO2R operation or when your transmit paths are different for HF and 6m
* Several new menus for additional customization of user preferences
* LP-100A now integrated with N4PY software
* Graphic VFD display with high contrast non-glare neutral density filter
* Front panel power switch
* Large scrolling call sign screen saver
* Setup screen for call sign entry
* Setup screen for display brightness
* Setup screen for screen saver timers
* Dual 40MHz Processors
* Per-band power calibration, user adjustable in 0.1% steps
* Frequency counter – user adjustable per-band corrections of all parameters.
* Only meter with Z, R, |X|, Phase display… not affected by local broadcast stations as antenna analyzers can be.
* Super wide autoranging power range of 50 mW to 3000W, 160-6m… perfect for QRPp through QRO
* Optional couplers for 5KW and 10KW. Our 10KW will handle more power and generate much less heat than our competitor’s.
* Only meter with Graphic VFD display. The graphic display allows for a solid bargraph with no gaps, and full screen scrolling screensaver as shown in the shot above with N8LP scrolling.
* Only meter with simultaneous bargraphs for Power and SWR (or Power and Ref Pwr).
* Highest bargraph resolution. 90 segments gives 1% tuning resolution with standard bargraph range settings (adjustable)
* Only meter that has a “sticky” bar to graphically show peak hold point even while bargraph is moving.
* Fast attack bargraph will accurately display a single “dit” at over 100 wpm. Decay adjustable for Fast, Med, Slow.
* Active temperature compensation. Only other meter with this is Alpha.
* True 12-bit A/D converter gives <1W resolution at 2000W. 13.6 bit effective resolution up to 360W.
* Return Loss (RL) display of 0 to 49.9 dB with bargraph
* Separate scale for dBm measurements, +15.0 dBm to +64.0 dBm with bargraph
* Field Strength input covers the range of  -15 dBm to +33 dBm (0.04 mW to 2W)… great for beam pattern and bench measurements
* Peak to Average ratio screen. Allows accurate checking and setting of compression in your speech processor.
* Support within TRX-Manager for direct remote monitoring
* Call sign screen saver – user programmable
* Free Plot program displays SWR, Z, Phase, R+jX (including sign), reflection coefficient, Return Loss and Smith chart.
* SWR alarm with “snooze” mode for antenna tuning. Alarm has LED, PTT relay and audible sounder (which can be easily disabled)
* G4HFQ’s free PolarPlot program works with the LP-100A’s Field Strength mode to provide automatic antenna pattern plotting. See software section of this web page.
* Separate coupler with 50 ohm ports for uncluttered desktop – remotable up to 50′ with appropriate calibration.
* Three autotanging scales with independently adjustable maximums.
* SWR display resolution is .01
* SWR error < .15  (5%) from about 100mW to 3000W, <.05 typical
* Power accuracy is better than 5% at any frequency from ~1W to maximum, 3% typical with NIST traceable factory calibration
* Power display is actual power delivered to the load ( Fwd minus Ref power) or traditional Fwd power.
* SWR Alarm system with set points for Off, 1.5, 2.0. 2.5, 3.0 and user setting. Audible & visual alarm, with PTT loop-thru & adjustable power threshold
* Windows® freeware Virtual Control Panel for software control or remote control.
* Built-in bootloader to allow for firmware upgrades to be downloaded and installed.
* Conforms to FCC Part 15 A & B, ICAS and CE radiated emission limits, tested and verified by accredited lab
